Ubiquiti Pro Max 16 Port PoE Ethernet Switch

What it does

The switch sits at the centre of the wired network. It connects UniFi access points and other equipment back to the comms location, supplies compatible devices over PoE, and provides Layer 3 network features for a more capable installation. The 2.5 GbE ports give suitable devices more headroom than a standard gigabit connection, while the 10G SFP+ ports provide high-speed uplinks.

Specification

• 16-port Ethernet switch
• 12 x 1 GbE RJ45 PoE+ ports
• 4 x 2.5 GbE RJ45 PoE++ ports
• 2 x 10G SFP+ uplink ports
• Up to 180 W total PoE availability
• 84 Gbps switching capacity
• 42 Gbps non-blocking throughput
• 62 Mpps forwarding rate
• Etherlighting support
• Rack-mount, desktop and wall-mount installation options

Who it suits

This is the right fit for a UniFi network with several wired access points, PoE devices or multi-gigabit connections. It suits a comms rack or central network location in a new build, extension or finished property where the cabling is already in place or can be added without major disruption.

What is not included

Hardware only. Network design, configuration, installation and cabling are quoted separately. If you want the gateway, switch and access points specified together, see the UniFi range.

Lead time

Lead time is confirmed at order. Talk to us before ordering if the date matters.
