Lyngdorf LS-1000: Premium Line Source Speaker for Exceptional Sound Dispersion
The Lyngdorf LS-1000 is crafted by our expert engineers, blending insights from the acclaimed Steinway & Sons LS models and Lyngdorf MH and FR speakers. Each LS-1000 module includes four 115mm midrange drivers with lightweight aluminum cones, 25mm voice coils, and powerful vented magnets, complemented by eight 1” soft dome tweeters. When four modules are combined, they create a robust line source with 16 midrange drivers and 32 tweeters, delivering unparalleled sound clarity and dynamic range.
Customizable Models for Optimal Sound Dispersion
To provide the best sound dispersion in various room configurations, the LS-1000 is available in three models:
- Lyngdorf LS-1000 Left: Designed for placement on the left side of the room, with sound slightly directed inward, away from the wall, optimizing sound toward the listening area.
- Lyngdorf LS-1000 Center: With centered tweeters, this model offers a balanced dispersion, ideal for use behind an acoustically transparent screen as a center speaker, or even as left and right speakers in wide rooms for expansive sound coverage.
- Lyngdorf LS-1000 Right: Positioned on the right side, it directs sound inward to focus audio into the listening area.
Enhanced Sound Quality with Reduced Reflections
The LS-1000 line source array minimizes floor and ceiling reflections by limiting vertical sound dispersion, ensuring listeners experience more direct sound from the speakers and less influence from room acoustics. The LS-1000 maintains consistent sound energy throughout the room, providing an even volume level for all listeners and expanding the “sweet spot” in all directions.
Modular, Rigid Construction for Easy Installation
With a slim, shallow cabinet and modular construction, the LS-1000 is easy to install, especially behind acoustically transparent screens. The rigid design minimizes resonance, and stacked modules connect via integrated contact pins, eliminating the need for external cables between modules.
Effortless Pairing with Amplifiers
Designed for versatility, the LS-1000 has an IEC power handling of 300 watts, a sensitivity of 98 dB (2.83V/1m), and an impedance of 4 ohms when using four modules. This combination allows for high-volume levels with a natural, effortless sound quality. With a frequency range extending from 20,000Hz down to 100Hz, the LS-1000 integrates seamlessly with woofers or subwoofers, especially the Lyngdorf BW-20, for a complete, powerful audio experience.
Specifications (LS-1000 Left / LS-1000 Right):
- Model: Lyngdorf LS-1000 Left / LS1000 Right
- Description: 2-way line source, closed
- Tweeter: 8 pcs 1″ soft dome
- Midrange driver: 4 pcs 115 mm, 25mm voice coil, aluminum cone, vented magnet
- Enclosure: MDF
- Frequency range: 100 – 20,000 Hz (-3 dB) (for four LS-1000 modules)
- Frequency extension: Down to 50 Hz depending on EQ
- Nominal Impedance: 16 Ohm (line source consisting of four LS-1000 modules: 4 Ohm)
- Sensitivity: 98 dB (2.83 V/1 m) (for four LS-1000 modules)
- Power handling: 300 W (IEC) (for four LS-1000 modules)
- Maximum SPL: 120 dB (for four LS-1000 modules)
- Crossover point: 1.8 kHz
- Connections: Screw terminals
- Mounting: In-wall
- Dimensions (W x H x D): 280 x 500 x 85 mm / 11 x 19.7 x 3.35 inches + mounting
- Weight: 9.9 kg / 21.8 lb
- Finish: Matte black
Specifications (LS-1000 Centre):
- Model: Lyngdorf LS-1000 Center
- Description: 2-way line source, closed
- Tweeter: 8 pcs 1″ soft dome
- Midrange driver: 4 pcs 115 mm, 25mm voice coil, aluminum cone, vented magnet
- Enclosure: MDF
- Frequency range: 100 – 20,000 Hz (-3 dB) (for four LS-1000 modules)
- Frequency extension: Down to 50 Hz depending on EQ
- Nominal Impedance: 16 Ohm (line source consisting of four LS-1000 modules: 4 Ohm)
- Sensitivity: 98 dB (2.83 V/1 m) (for four LS-1000 modules)
- Power handling: 300 W (IEC) (for four LS-1000 modules)
- Maximum SPL: 120 dB (for four LS-1000 modules)
- Crossover point: 1.8 kHz
- Connections: Screw terminals
- Mounting: In-wall
- Dimensions (W x H x D): 280 x 500 x 132 mm / 11 x 19.7 x 5.2 inches + mounting
- Weight: 10.4 kg / 22.9 lb
- Finish: Matte black
