Features
-
Integrated DALI Speaker Presets: Built-in DSP with model-specific presets ensures optimal performance for any DALI CI audio installation.
-
Powerful Class-D Amplification: Delivers 2 x 500 watts of ultra-low distortion, high-efficiency power, or can be bridged to 1,000 watts for mono applications.
-
Web-Based Configurator: Manage DSP tools like parametric equalizers, audio limiters, routing matrix, and speaker settings via a web interface on any device.
-
Wide Range of Applications: Ideal for home cinema, multi-room audio, and commercial setups like bars, restaurants, gyms, and retail environments.
-
Exclusive Partner for PHANTOM SUB S-100: Designed to seamlessly power up to four SUB S-100 subwoofers with integrated DSP matching.
Advanced DSP and Speaker Presets
The PHANTOM CI AMP-2500 DSP amplifier incorporates advanced Digital Signal Processing to optimize performance for any setup. With model-specific speaker presets and user-friendly control via a web-based interface, you can fine-tune your system for maximum clarity and impact.
High-Efficiency Class-D Amplification
Featuring 2 x 500 watts of Danish-developed Class-D amplification, the AMP-2500 DSP ensures effortless power delivery with ultra-low distortion. For larger setups, the amplifier can be bridged into a 1,000-watt mono configuration, making it the perfect power source for the PHANTOM S and M series and up to four PHANTOM IW SUB S-100 subwoofers.
Web-Based Control from Any Device
Configure and control your system with ease using the PHANTOM AMP configurator. This web-based interface allows access to powerful DSP tools, including parametric equalizers, routing matrix, speaker delay, and presets, all from your PC, tablet, or smartphone.
Versatile Applications
While the PHANTOM CI AMP-2500 DSP is designed primarily for high-performance home cinemas, it’s also an excellent choice for powering in-wall and in-ceiling speakers in multi-room audio setups. Additionally, it’s a great solution for commercial spaces such as bars, restaurants, gyms, and retail environments, where powerful and reliable audio is essential.
The Perfect Partner for PHANTOM SUB S-100
Specifically designed to complement the PHANTOM SUB S-100, the AMP-2500 DSP provides enough power to drive up to four SUB S-100 subwoofers. Its integrated DSP has been fine-tuned to match the SUB S-100’s sound profile, ensuring perfectly balanced bass for even the largest rooms.
Power Your Audio System with Confidence
The PHANTOM CI AMP-2500 DSP Amplifier combines power, versatility, and advanced features to deliver exceptional performance for any custom audio setup. Whether you’re building a state-of-the-art home theater or outfitting a commercial space, this amplifier offers unmatched quality and control.
Specifications:
-
Frequency Range: 12 Hz – 20 kHz (+/- 0.5 dB, 8 Ω load, 3 dB below rated power)
-
Connection Input(s): 4x Analog unbalanced, RCA, 4x Analog balanced, Euroblock connector, 1x S/PDIF, RCA
-
Input Impedance: 10 kOhm
-
Output Channels: 2 x Lo-Z speaker (4 - 16 ohm), 1 x Hi-Z speaker (70V / 100V), 1x S/PDIF digital out, RCA
-
Maximum Speaker Cable Cross Section: 2.5 mm² / AWG 14 (Euroblock standard)
-
Output Power: @ 2 ohm: 2 x 500 W (SE) * / @ 4 ohm: 2 x 500 W (SE), 1 x 1000 W (BTL) / @ 8 ohm: 2 x 250 W (SE), 1 x 1000 W (BTL) / @ 70V: 1 x 1000 W (BTL) / @ 100V: 1 x 1000 W (BTL)
-
Total System Power: 1000 W
-
Power Consumption: 350 W
-
Output Voltage: 45 Vrms (SE) - 90 Vrms (BTL), 70/100V (Hi-Z)
-
Output Circuitry: UMAC™ Class D - full bandwidth PWM modulator with ultra-low distortion
-
Signal-to-Noise Ratio: >108 dB (A-weighted, 20 Hz - 20 kHz, 8 Ω load)
-
THD+N (Typical): < 0.05 % (20 Hz - 20 kHz, 8 Ω load, 3 dB below rated power)
-
Other Features: Short circuit protection, DC protection, Undervoltage protection, Temperature protection, Overload protection, Rack mountable
-
Power Supply: UREC™ universal mains switch mode power supply with Power Factor Correction (PFC) and standby converter
-
Operating Temperature: 0 - 40° C
-
Operating Voltage/Frequency: Universal mains, 100 V-240 V, 50 Hz-60 Hz
-
Power Ratings: 1 % THD @ 120 Vac and 230 Vac
-
Standby Consumption: < 0.5 W
-
Outer Dimensions (H x W x D): 88 x 440 x 332 mm / 3.5 x 17.3 x 13.1 inches
-
Weight: 5.9 kg / 13 lb
-
Shipping Weight: 7.5 kg / 16.5 lb
-
Accessories: 2x Two channel balanced input connector, 1x Two channel speaker output connector, 1x GPIO socket connector, 1x Mains power cable, 4x Adhesive rubber feet, 2x Rack mount ears (mounted)
